Brand new aftermarket stator
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation.
- Highest grade lamination materials
- Highest grade copper windings, resistant to 200 degrees Celsius.
- Pick up pulsar coil included
- Connector included
- Rubber grommet included
Dimensions :
Interior diameter : 34mm
Exterior diameter : 83mm
Thickness : 14mm
Length of wires stator to grommet : 90mm
Length of wires grommet to plug : 225mm
Length of pickup coil's wire to grommet : 160mm
Other specifications :
Number of wires : 6
Number of plugs : 3
Number of pins : 6
Wire to wire resistance :
Alternator : Yellow to White = 0.4ohms +/-20%
Pickup : Green/White to Blue/Yellow = 275ohms +/-20%
Source : Black to Brown = 475ohms +/-20%
1993 Yamaha YFB 250 Timberwolf
1992 Yamaha YFB 250 Timberwolf
